Lenticular Depth filter module is also called stack filter. It is used for lenticular filter housing which is widely used in winery and brewery. Depth filtration modules allow to handle large filter areas easily in a disposable assembly. Filtration is performed in a closed system. Depth filter sheets inside have a high dirt holding capacity.
Material of Constructions: Depth filter sheet. Cellulose fibers. Natural diatomaceous earth, Perlite, Resins. And Etc Core/Separator: Polypropylene (PP). Double o ring or Flat gasket type, 1-3um 2-5um 5-7um available.
Features–Benefits
• Proven performance cellulose based filter sheet media
• Choice of DE or perlite filter aids
• Nominal retention ratings from 0.25 to 15 microns
• High efficiency due to positive zeta potential
• Exceptional mechanical strength
• Choice of flat gasket seal or double o-ring seal
• Choice of economical stainless steel bands or rigid molded polypropylene core
• Special water absorbing component is available in the 10 and 15 micron grades
• Steam sterilizable
• Media grade stamped on sheets for easy identification
